FEATURE
Uncooled microbolometer infrared focal plane arrays, 324×256 pixel
High sensitivity, NETD at 50mk, 25Hz
- 3X continuous zoom, can search in wide range, and recognize target in the distance
Dynamic Detail Enhancer (DDE) function; output white hot / black hot / color palette
Low consumption, clear image, stable performance
RS 485 serial interface, analog video signal output
Easy to operate and maintain
Sealed shell, smart shape, nitrogen inside, anti-harsh environment . Fulfills some MIL specifications and system is very mrugged and have a high stability. vibration tested and shock tested
Tested in salt spray and unde sevee conditions.
PARAMETER
Distance to detect following Objects
Human(1.8m×0.5m) Detect 960m Recognize 330m
Vehicle (2.3m×2.3m) Detect 2640m
Thermal Camera
Focal Length 20~60mm,3x optical zoom
FOV 11.6°×9.3°~33.8°×27.3°
Spatial Resolution 0.63~1.90mrad
Lens Control motor drive zoom and focus(auto focus is optional)
Detector Type Resolution 320×256
Spectral Range 8~14μm
NETD ≤50mK@F1.0, 300K
Frame Frequency 25Hz
Heterogeneity Adjustment auto/manual/background adjustment
Image Process DDE,pseudo color
Video Output PAL/NTSC
Interface Power DC12V
Others RS485,BNC video output
Environment Work T emperature -25°C~+55°C
Store Temperature -40°C~+70°C
Protection IP65
Vibration 10~200Hz,0.75mm
Impact 150m/s2,11ms
Anti-Salt Fog PH6.5~7.2,spray 48 hours
Power Power Supply DC12V
Total Power ≤8W
Physic Weight 1.8Kg
Size 251mm×115mm×117mm(L×W×H,include shield)
