GLM5-532 Description
The GLM5-532 is a green laser subassembly with collimated beam. The maximum laser output power is 5.0 mW at 532nm. This is a diode pumped Yag of new generation with extended temperature range of 0 to 45 C. Laser is bore sighted to max 6 mm at 1 meter in distance and this is far better than most modules. Moderate power needs makes it suitable for battery applications.
Features
- Wavelength: 532 nm
- High brightness, optical output power: <5.0 mW
- Low operating current: <200mA
- Low operating voltage: 3VDC
- Class IIIa laser, CDRH/ROHS compatible
- Static, Surge, and Reverse Polarity Protected
- Circuit control: Auto power control
- Operating Temperature: 0 to 45°C
- No APC power stabilizing
